complexPTcomputational(3) | LAPACK | complexPTcomputational(3) |

# NAME¶

complexPTcomputational - complex

# SYNOPSIS¶

## Functions¶

subroutine **cptcon** (N, D, E, ANORM, RCOND, RWORK, INFO)

**CPTCON** subroutine **cpteqr** (COMPZ, N, D, E, Z, LDZ, WORK, INFO)

**CPTEQR** subroutine **cptrfs** (UPLO, N, NRHS, D, E, DF, EF, B, LDB,
X, LDX, FERR, BERR, WORK, RWORK, INFO)

**CPTRFS** subroutine **cpttrf** (N, D, E, INFO)

**CPTTRF** subroutine **cpttrs** (UPLO, N, NRHS, D, E, B, LDB, INFO)

**CPTTRS** subroutine **cptts2** (IUPLO, N, NRHS, D, E, B, LDB)

**CPTTS2** solves a tridiagonal system of the form AX=B using the L D LH
factorization computed by spttrf.

# Detailed Description¶

This is the group of complex computational functions for PT matrices

# Function Documentation¶

## subroutine cptcon (integer N, real, dimension( * ) D, complex, dimension( * ) E, real ANORM, real RCOND, real, dimension( * ) RWORK, integer INFO)¶

**CPTCON**

**Purpose:**

CPTCON computes the reciprocal of the condition number (in the

1-norm) of a complex Hermitian positive definite tridiagonal matrix

using the factorization A = L*D*L**H or A = U**H*D*U computed by

CPTTRF.

Norm(inv(A)) is computed by a direct method, and the reciprocal of

the condition number is computed as

RCOND = 1 / (ANORM * norm(inv(A))).

**Parameters**

*N*

N is INTEGER

The order of the matrix A. N >= 0.

*D*

D is REAL array, dimension (N)

The n diagonal elements of the diagonal matrix D from the

factorization of A, as computed by CPTTRF.

*E*

E is COMPLEX array, dimension (N-1)

The (n-1) off-diagonal elements of the unit bidiagonal factor

U or L from the factorization of A, as computed by CPTTRF.

*ANORM*

ANORM is REAL

The 1-norm of the original matrix A.

*RCOND*

RCOND is REAL

The reciprocal of the condition number of the matrix A,

computed as RCOND = 1/(ANORM * AINVNM), where AINVNM is the

1-norm of inv(A) computed in this routine.

*RWORK*

RWORK is REAL array, dimension (N)

*INFO*

INFO is INTEGER

= 0: successful exit

< 0: if INFO = -i, the i-th argument had an illegal value

**Author**

Univ. of California Berkeley

Univ. of Colorado Denver

NAG Ltd.

**Further Details:**

The method used is described in Nicholas J. Higham, "Efficient

Algorithms for Computing the Condition Number of a Tridiagonal

Matrix", SIAM J. Sci. Stat. Comput., Vol. 7, No. 1, January 1986.

## subroutine cpteqr (character COMPZ, integer N, real, dimension( * ) D, real, dimension( * ) E, complex, dimension( ldz, * ) Z, integer LDZ, real, dimension( * ) WORK, integer INFO)¶

**CPTEQR**

**Purpose:**

CPTEQR computes all eigenvalues and, optionally, eigenvectors of a

symmetric positive definite tridiagonal matrix by first factoring the

matrix using SPTTRF and then calling CBDSQR to compute the singular

values of the bidiagonal factor.

This routine computes the eigenvalues of the positive definite

tridiagonal matrix to high relative accuracy. This means that if the

eigenvalues range over many orders of magnitude in size, then the

small eigenvalues and corresponding eigenvectors will be computed

more accurately than, for example, with the standard QR method.

The eigenvectors of a full or band positive definite Hermitian matrix

can also be found if CHETRD, CHPTRD, or CHBTRD has been used to

reduce this matrix to tridiagonal form. (The reduction to

tridiagonal form, however, may preclude the possibility of obtaining

high relative accuracy in the small eigenvalues of the original

matrix, if these eigenvalues range over many orders of magnitude.)

**Parameters**

*COMPZ*

COMPZ is CHARACTER*1

= 'N': Compute eigenvalues only.

= 'V': Compute eigenvectors of original Hermitian

matrix also. Array Z contains the unitary matrix

used to reduce the original matrix to tridiagonal

form.

= 'I': Compute eigenvectors of tridiagonal matrix also.

*N*

N is INTEGER

The order of the matrix. N >= 0.

*D*

D is REAL array, dimension (N)

On entry, the n diagonal elements of the tridiagonal matrix.

On normal exit, D contains the eigenvalues, in descending

order.

*E*

E is REAL array, dimension (N-1)

On entry, the (n-1) subdiagonal elements of the tridiagonal

matrix.

On exit, E has been destroyed.

*Z*

Z is COMPLEX array, dimension (LDZ, N)

On entry, if COMPZ = 'V', the unitary matrix used in the

reduction to tridiagonal form.

On exit, if COMPZ = 'V', the orthonormal eigenvectors of the

original Hermitian matrix;

if COMPZ = 'I', the orthonormal eigenvectors of the

tridiagonal matrix.

If INFO > 0 on exit, Z contains the eigenvectors associated

with only the stored eigenvalues.

If COMPZ = 'N', then Z is not referenced.

*LDZ*

LDZ is INTEGER

The leading dimension of the array Z. LDZ >= 1, and if

COMPZ = 'V' or 'I', LDZ >= max(1,N).

*WORK*

WORK is REAL array, dimension (4*N)

*INFO*

INFO is INTEGER

= 0: successful exit.

< 0: if INFO = -i, the i-th argument had an illegal value.

> 0: if INFO = i, and i is:

<= N the Cholesky factorization of the matrix could

not be performed because the i-th principal minor

was not positive definite.

> N the SVD algorithm failed to converge;

if INFO = N+i, i off-diagonal elements of the

bidiagonal factor did not converge to zero.

**Author**

Univ. of California Berkeley

Univ. of Colorado Denver

NAG Ltd.

## subroutine cptrfs (character UPLO, integer N, integer NRHS, real, dimension( * ) D, complex, dimension( * ) E, real, dimension( * ) DF, complex, dimension( * ) EF, complex, dimension( ldb, * ) B, integer LDB, complex, dimension( ldx, * ) X, integer LDX, real, dimension( * ) FERR, real, dimension( * ) BERR, complex, dimension( * ) WORK, real, dimension( * ) RWORK, integer INFO)¶

**CPTRFS**

**Purpose:**

CPTRFS improves the computed solution to a system of linear

equations when the coefficient matrix is Hermitian positive definite

and tridiagonal, and provides error bounds and backward error

estimates for the solution.

**Parameters**

*UPLO*

UPLO is CHARACTER*1

Specifies whether the superdiagonal or the subdiagonal of the

tridiagonal matrix A is stored and the form of the

factorization:

= 'U': E is the superdiagonal of A, and A = U**H*D*U;

= 'L': E is the subdiagonal of A, and A = L*D*L**H.

(The two forms are equivalent if A is real.)

*N*

N is INTEGER

The order of the matrix A. N >= 0.

*NRHS*

NRHS is INTEGER

The number of right hand sides, i.e., the number of columns

of the matrix B. NRHS >= 0.

*D*

D is REAL array, dimension (N)

The n real diagonal elements of the tridiagonal matrix A.

*E*

E is COMPLEX array, dimension (N-1)

The (n-1) off-diagonal elements of the tridiagonal matrix A

(see UPLO).

*DF*

DF is REAL array, dimension (N)

The n diagonal elements of the diagonal matrix D from

the factorization computed by CPTTRF.

*EF*

EF is COMPLEX array, dimension (N-1)

The (n-1) off-diagonal elements of the unit bidiagonal

factor U or L from the factorization computed by CPTTRF

(see UPLO).

*B*

B is COMPLEX array, dimension (LDB,NRHS)

The right hand side matrix B.

*LDB*

LDB is INTEGER

The leading dimension of the array B. LDB >= max(1,N).

*X*

X is COMPLEX array, dimension (LDX,NRHS)

On entry, the solution matrix X, as computed by CPTTRS.

On exit, the improved solution matrix X.

*LDX*

LDX is INTEGER

The leading dimension of the array X. LDX >= max(1,N).

*FERR*

FERR is REAL array, dimension (NRHS)

The forward error bound for each solution vector

X(j) (the j-th column of the solution matrix X).

If XTRUE is the true solution corresponding to X(j), FERR(j)

is an estimated upper bound for the magnitude of the largest

element in (X(j) - XTRUE) divided by the magnitude of the

largest element in X(j).

*BERR*

BERR is REAL array, dimension (NRHS)

The componentwise relative backward error of each solution

vector X(j) (i.e., the smallest relative change in

any element of A or B that makes X(j) an exact solution).

*WORK*

WORK is COMPLEX array, dimension (N)

*RWORK*

RWORK is REAL array, dimension (N)

*INFO*

INFO is INTEGER

= 0: successful exit

< 0: if INFO = -i, the i-th argument had an illegal value

**Internal Parameters:**

ITMAX is the maximum number of steps of iterative refinement.

**Author**

Univ. of California Berkeley

Univ. of Colorado Denver

NAG Ltd.

## subroutine cpttrf (integer N, real, dimension( * ) D, complex, dimension( * ) E, integer INFO)¶

**CPTTRF**

**Purpose:**

CPTTRF computes the L*D*L**H factorization of a complex Hermitian

positive definite tridiagonal matrix A. The factorization may also

be regarded as having the form A = U**H *D*U.

**Parameters**

*N*

N is INTEGER

The order of the matrix A. N >= 0.

*D*

D is REAL array, dimension (N)

On entry, the n diagonal elements of the tridiagonal matrix

A. On exit, the n diagonal elements of the diagonal matrix

D from the L*D*L**H factorization of A.

*E*

E is COMPLEX array, dimension (N-1)

On entry, the (n-1) subdiagonal elements of the tridiagonal

matrix A. On exit, the (n-1) subdiagonal elements of the

unit bidiagonal factor L from the L*D*L**H factorization of A.

E can also be regarded as the superdiagonal of the unit

bidiagonal factor U from the U**H *D*U factorization of A.

*INFO*

INFO is INTEGER

= 0: successful exit

< 0: if INFO = -k, the k-th argument had an illegal value

> 0: if INFO = k, the leading minor of order k is not

positive definite; if k < N, the factorization could not

be completed, while if k = N, the factorization was

completed, but D(N) <= 0.

**Author**

Univ. of California Berkeley

Univ. of Colorado Denver

NAG Ltd.

## subroutine cpttrs (character UPLO, integer N, integer NRHS, real, dimension( * ) D, complex, dimension( * ) E, complex, dimension( ldb, * ) B, integer LDB, integer INFO)¶

**CPTTRS**

**Purpose:**

CPTTRS solves a tridiagonal system of the form

A * X = B

using the factorization A = U**H*D*U or A = L*D*L**H computed by CPTTRF.

D is a diagonal matrix specified in the vector D, U (or L) is a unit

bidiagonal matrix whose superdiagonal (subdiagonal) is specified in

the vector E, and X and B are N by NRHS matrices.

**Parameters**

*UPLO*

UPLO is CHARACTER*1

Specifies the form of the factorization and whether the

vector E is the superdiagonal of the upper bidiagonal factor

U or the subdiagonal of the lower bidiagonal factor L.

= 'U': A = U**H*D*U, E is the superdiagonal of U

= 'L': A = L*D*L**H, E is the subdiagonal of L

*N*

N is INTEGER

The order of the tridiagonal matrix A. N >= 0.

*NRHS*

NRHS is INTEGER

The number of right hand sides, i.e., the number of columns

of the matrix B. NRHS >= 0.

*D*

D is REAL array, dimension (N)

The n diagonal elements of the diagonal matrix D from the

factorization A = U**H*D*U or A = L*D*L**H.

*E*

E is COMPLEX array, dimension (N-1)

If UPLO = 'U', the (n-1) superdiagonal elements of the unit

bidiagonal factor U from the factorization A = U**H*D*U.

If UPLO = 'L', the (n-1) subdiagonal elements of the unit

bidiagonal factor L from the factorization A = L*D*L**H.

*B*

B is COMPLEX array, dimension (LDB,NRHS)

On entry, the right hand side vectors B for the system of

linear equations.

On exit, the solution vectors, X.

*LDB*

LDB is INTEGER

The leading dimension of the array B. LDB >= max(1,N).

*INFO*

INFO is INTEGER

= 0: successful exit

< 0: if INFO = -k, the k-th argument had an illegal value

**Author**

Univ. of California Berkeley

Univ. of Colorado Denver

NAG Ltd.

## subroutine cptts2 (integer IUPLO, integer N, integer NRHS, real, dimension( * ) D, complex, dimension( * ) E, complex, dimension( ldb, * ) B, integer LDB)¶

**CPTTS2** solves a tridiagonal system of the form AX=B using
the L D LH factorization computed by spttrf.

**Purpose:**

CPTTS2 solves a tridiagonal system of the form

A * X = B

using the factorization A = U**H*D*U or A = L*D*L**H computed by CPTTRF.

D is a diagonal matrix specified in the vector D, U (or L) is a unit

bidiagonal matrix whose superdiagonal (subdiagonal) is specified in

the vector E, and X and B are N by NRHS matrices.

**Parameters**

*IUPLO*

IUPLO is INTEGER

Specifies the form of the factorization and whether the

vector E is the superdiagonal of the upper bidiagonal factor

U or the subdiagonal of the lower bidiagonal factor L.

= 1: A = U**H *D*U, E is the superdiagonal of U

= 0: A = L*D*L**H, E is the subdiagonal of L

*N*

N is INTEGER

The order of the tridiagonal matrix A. N >= 0.

*NRHS*

NRHS is INTEGER

The number of right hand sides, i.e., the number of columns

of the matrix B. NRHS >= 0.

*D*

D is REAL array, dimension (N)

The n diagonal elements of the diagonal matrix D from the

factorization A = U**H *D*U or A = L*D*L**H.

*E*

E is COMPLEX array, dimension (N-1)

If IUPLO = 1, the (n-1) superdiagonal elements of the unit

bidiagonal factor U from the factorization A = U**H*D*U.

If IUPLO = 0, the (n-1) subdiagonal elements of the unit

bidiagonal factor L from the factorization A = L*D*L**H.

*B*

B is COMPLEX array, dimension (LDB,NRHS)

On entry, the right hand side vectors B for the system of

linear equations.

On exit, the solution vectors, X.

*LDB*

LDB is INTEGER

The leading dimension of the array B. LDB >= max(1,N).

**Author**

Univ. of California Berkeley

Univ. of Colorado Denver

NAG Ltd.

# Author¶

Generated automatically by Doxygen for LAPACK from the source code.

Wed Sep 1 2021 | Version 3.10.0 |
